Functional Features Scara robotwith compact and flexible structure, fast running speed, high transmission accuracy and low noiseRobotic automationhighly rigid arm design realizes high load and high speed in one packageAvailable in 600 and 400mm arm span; 3kg or 6kg payloadSCARA robot …
Item No.: EVS3-400H
Payment: T/T
Product Origin: China
Shipping Port: Shanghai or designated port
Lead Time: 15-30 working days
| ModelA2:C22 | EVS3-400H | |
| Function | material handling, 3C products | |
| Total axes | 4 | |
| Maximum reach | 400mm | |
| Payload | rated load | 1kg |
| maximum load | 3kg | |
| Permissible inertial torque of rotating axis | rated torque | 0.005kg·m2 |
| maximum torque | 0.05kg·m2 | |
| Repeated positioning accuracy | 1st axis+2nd axis | ±0.01mm |
| 3rd axis (elevating axis) | ±0.01mm | |
| 4th axis (rotation axis) | ±0.01° | |
| Max speed | 1st axis | 6000mm/s |
| 2nd axis | 6000mm/s | |
| 3rd axis (elevating axis) | 1000mm/s | |
| 4th axis (rotation axis) | 2600°/sec | |
| Max operating area | 1st axis | ±132° |
| 2nd axis | ±141° | |
| 3rd axis (elevating axis) | 150mm | |
| 4th axis (rotation axis) | ±360° | |
| Installation form | Floor mounted | |
| Robot weight | 16Kg | |
| Power consumption | 0.7kw | |
| Installation environment | Temperature | 0~+45℃ |
| Humidity | 20~80%RH (no condensation) | |
| Vibration | Under 4.9M/S131 | |
